CPU
2x up to 128 core AMD EPYC Genoa/Bergamo
-
MEMORY
24x DDR5 4800MHz DIMM sockets (Max: 3 TB)
-
STORAGE
4x 3.5"SATA,NVMe drive bays (Max: 88 TB)
-
DENSITY
1U rackmount chassis with redundant power
Discounts are available for volume, education and government customers. Request a quote for product and pricing details.
Technical Specifications
In the box
- ACTserv e1416 system
- Documentation
Processor
- 2x AMD Genoa/Bergamo series processors
- AMD Genoa/Bergamo microarchitecture
Chipset
- AMD Genoa/Bergamo chipset
Memory
- 4800MHz DDR5 memory
- 24x DIMM sockets for support up to 3TB
Storage
- 4x 3.5" SATA/U.2 NVMe drives
Management
- Integrated IPMI 2.0 module
- Integrated management controller providing iKVM and remote disk emulation
I/O Connections
- 2x PCI-e Gen5 x16 & 1x Gen5 x8 PCI-e slots
- 2x Rear USB ports
- 1x VGA
- 1x Dedicated RJ45 IPMI ethernet
Electrical requirements
- High-efficiency power supply (greater than 90%)
- Output power: Single or Dual 1600W
- Universal input voltage 100V to 208V (minimum required to run at full capacity)
- Frequency: 50Hz to 60Hz, single phase
Operating System
- RedHat Linux 8 and newer (many other distributions supported, call for details)
