A newer version of this model is now available
This model has been replaced by a newer model, the ACTstation x330.
  • CPU

    1x up to 18 core Intel Xeon W (Skylake)

  • MEMORY

    8x DDR4 2666MHz DIMM sockets (Max: 512 GB)

  • STORAGE

    8x 3.5"SATA,NVMe drive bays (Max: 96 TB)

  • ACCELERATORS

    Max 2x NVIDIA Quadro, NVIDIA GTX accelerators

  • CONNECTIVITY

    Onboard 2x 1Gb NICs & Optional: 10GbE, 40GbE

  • DENSITY

    Desktop chassis

Discounts are available for volume, education and government customers. Request a quote for product and pricing details.

Related System

Dual Socket Xeon workstation

  • product-img
    ACTstation x150

    Our most powerful workstation gives you the power of HPC on your desktop. This workstation is
    quiet and air cooled.
Holds up to two NVIDIA GPUs.
Up to 56 cores and 768 GB memory.

    Configure

Technical Specifications

In the box
  • Workstation system
  • Optional keyboard and optical mouse
  • 110V or 208V power cord
  • Documentation
Processor
  • Closed loop water cooling system for maximum performance and minimal noise
  • Intel Quad Core Xeon W processor
  • Intel "Skylake" microarchitecture
Accelerators
  • Space for up to 2x Dual-Slot GPUs
Chipset
  • Intel C422
Memory
  • 2666MHz DDR4 memory
  • 8x DIMM sockets for support up to 512GB
Storage
  • Up to 8x 10TB SATA 6Gb/s Enterprise Hard Drive 7200RPM w/128MB Cache
  • Optional 2x U.2 NVMe drives
Management
  • Remote iKVM with dedicated management RJ45 ethernet
I/O Connections
  • 2x independent 1Gb RJ-45 ethernet interfaces
  • 4x USB 3.0, 2x USB 2.0
  • 7.1-Channel High Definition Audio (analog and S/PDIF)
Electrical requirements
  • High-efficiency power supply (greater than 80%)
  • Output power: 850W - 1300W power supply
  • Universal input voltage 100V to 240V
  • Frequency: 50Hz to 60Hz, single phase
Size & Weight
  • Height: 21.0 inches
  • Width: 9.5 inches
  • Depth: 22.9 inches
  • Weight: Base config 40lbs, varies based on configuration
