A newer version of this model is now available
This model has been replaced by a newer model, the ACTserv x2280c.
  • CPU

    2x up to 28 core Intel Xeon SP (Cascade Lake)

  • MEMORY

    24x DDR4 2933MHz DIMM sockets (Max: 1.5 TB)

  • STORAGE

    14x 2.5" SATA,SSD drive bays (Max: 53.76 TB)

  • ACCELERATORS

    Max 8x NVIDIA Tesla, NVIDIA Quadro, NVIDIA GTX accelerators

  • CONNECTIVITY

    Onboard 2x 10Gb NICs & Optional: 10GbE, 40GbE, InfiniBand, OmniPath, 100GbE

  • DENSITY

    4U rackmount chassis with redundant power

Discounts are available for volume, education and government customers. Request a quote for product and pricing details.

Technical Specifications

In the box
  • ACTserv system
  • Documentation
Processor
  • 2x Intel Xeon SP series processors
  • Intel "Cascade Lake" microarchitecture
Chipset
  • Intel C624 series
Memory
  • 2933MHz DDR4 memory
  • 24x DIMM sockets for support up to 1.5TB
Storage
  • 14x 2.5" SATA drive bay for Hard Drive / SSD
Management
  • Remote iKVM with in-band management
I/O Connections
  • 1Gb Ethernet
  • 10Gb Ethernet
  • 40Gb Ethernet
  • InfiniBand
  • Omni-Path
Electrical requirements
  • 2+1 Redundant 80+
Size & Weight
  • Height: 7 inches (4U)
  • Width: 17 inches
  • Depth: 31 inches
  • Weight: Base config 80 lbs.; varies based on configuration
Operating System
  • RedHat Linux 6 and newer (most other distributions supported, call for details)
