A newer version of this model is now available
This model has been replaced by a newer model, the ACTserv e2280c.
-
CPU
2x up to 32 core AMD EPYC (Naples)
-
MEMORY
32x DDR4 2666MHz DIMM sockets (Max: 4 TB)
-
STORAGE
8x 3.5"SATA,SSD drive bays (Max: 96 TB)
-
ACCELERATORS
Max 2x NVIDIA Tesla accelerators
-
CONNECTIVITY
Onboard 2x 10Gb NICs & Optional: 10GbE, 40GbE, InfiniBand, 100GbE
-
DENSITY
2U rackmount chassis with redundant power
Discounts are available for volume, education and government customers. Request a quote for product and pricing details.
Technical Specifications
In the box
- ACTserv e2120 system
- Documentation
Processor
- 2x AMD EPYC 7001 series processors
- AMD EPYC "Naples" microarchitecture
Accelerators
- Optional 2x dual height, full length GPUs (NVIDIA Tesla)
Chipset
- AMD EPYC SoC
Memory
- 2666MHz DDR4 memory
- 32x DIMM sockets for support up to 4TB
Storage
- 12x 3.5" hot-swap SATA drive bay
- Support RAID level 0,1,10,5,6 with Linux software RAID or optional hardware RAID controller
- Support for high-performance solid state drives (SSD)
Management
- Integrated IPMI 2.0 module
- Integrated management controller providing iKVM and remote disk emulation
I/O Connections
- 3x GPU expansion slots PCI-e 3.0 running at 16x
- 1x PCI-e 3.0 at 16x
- 2x PCI-e 3.0 at 8x
- 2x independent 1GbE BaseT Ethernet interfaces
- 5x USB 3.0 ports
Electrical requirements
- High-efficiency redundant 2000W power supply (greater than 90%)
- Universal input voltage 100V to 240V
Size & Weight
- Height: 3.5 inches (2U)
- Width: 19 inches
- Depth: 28 inches
- Weight: Base config 65lbs, varies based on configuration
Operating System
- RedHat Linux 7 and newer (most other distributions supported, call for details)
