MSRP price as configured. $0.00
A newer version of this model is now available
This model has been replaced by a newer model, the ACTserv x2440c.
  • CPU

    2x up to 40 core Intel Xeon (Ice Lake)

  • MEMORY

    16x DDR4 3200MHz DIMM sockets (Max: 2 TB)

  • STORAGE

    2x 2.5" & 2x M.2 NVMe drive bays (Max: 16 TB)

  • ACCELERATORS

    Max 4x NVIDIA Tesla accelerators

  • CONNECTIVITY

    Onboard 1x 10Gb NICs & Optional: 10GbE, 40GbE, InfiniBand, 100GbE

  • DENSITY

    Compute Block rackmount chassis with redundant power

Discounts are available for volume, education and government customers. Request a quote for product and pricing details.

Additional node types

The Intel Xeon IceLake ACTblade family consists of other node types including air and liquid cooled compute, storage, and managent nodes

  • product-img
    ACTblade x310

    2U, 4 node air-cooled compute nodes

    Configure
  • product-img
    ACTblade x320

    2U, 2 node management nodes

    Configure
  • product-img
    ACTblade x350

    2U, 2 storage nodes

    Configure

Technical Specifications

In the box
  • ACTblade x380c system
  • Documentation
Processor
  • 2x 3nd generation Intel Xeon SP series processors
  • Intel "Ice Lake" microarchitecture
Accelerators
  • Up to 4x Dual width dual height Accelerators or GPUs (i.e. NVIDIA Tesla)
Chipset
  • Intel C621A series
Memory
  • 3200MHz DDR4 Memory
  • 16x DIMM sockets for support up to 2TB
Storage
  • 2x 110mm M.2 SATA/NVMe SSDs
  • 2x U.2 2.5" NVMe SSDs
Management
  • Integrated IPMI 2.0 module
  • Integrated management controller providing iKVM and remote disk emulation
I/O Connections
  • 4x open PCI-e 4.0 expansion slot running at 16x
  • 4x open PCI-e 4.0 dual slot accelerator/GPU slots running at 16x
  • 1x independent 10Gb RJ-45 ethernet interfaces
  • 1x USB port
  • Via management dongle: 2x USB ports, 1x VGA, 1x DB9 serial
Electrical requirements
  • High-efficiency power supply (greater than 90%)
  • Output power: 3x 1600W
  • Universal input voltage 100V to 240V
  • Frequency: 50Hz to 60Hz, single phase
Operating System
  • RedHat Linux 8 and newer (many other distributions supported, call for details)
