A newer version of this model is now available
This model has been replaced by a newer model, the ACTblade e230.
  • CPU per node

    2x up to 32 core AMD EPYC (Naples)

  • MEMORY per node

    16x DDR4 2666MHz DIMM sockets (Max: 2 TB)

  • STORAGE per node

    6x 2.5" SATA drive bays (Max: 23.04 TB)

  • CONNECTIVITY per node

    Onboard 2x 1Gb NICs & Optional: 10GbE, 40GbE, InfiniBand, 100GbE

  • DENSITY

    Compute Block multi-node rackmount chassis with redundant power

Discounts are available for volume, education and government customers. Request a quote for product and pricing details.

Technical Specifications

In the box
  • ACTblade e130 system
  • Documentation
Processor (per node)
  • 2x AMD EPYC 7001 series processors
  • AMD EPYC "Naples" microarchitecture
Chipset (per node)
  • AMD EPYC SoC
Memory (per node)
  • 2666MHz DDR4 memory
  • 16x DIMM sockets for support up to 1TB
Storage (per node)
  • 6x 2.5" SATA/SSD drive bay
Management (per node)
  • Integrated IPMI 2.0 module
  • Integrated management controller providing iKVM and remote disk emulation
I/O Connections (per node)
  • 2x open PCI-e 3.0 expansion slot running at 16x
  • 2x independent 1Gb RJ-45 ethernet interfaces
  • 2x USB ports
  • 1x VGA port
Electrical requirements
  • High-efficiency power supply (greater than 90%)
  • Output power: redundant 2200W
  • Universal input voltage 100V to 240V
  • Frequency: 50Hz to 60Hz, single phase
Size & Weight
  • Height: 3.5 inches (2U)
  • Width: 19 inches
  • Depth: 32 inches
  • Weight: Base config 100lbs, varies based on configuration
Operating System (per node)
  • RedHat Linux 7 and newer (most other distributions supported, call for details)
