ACTblade e130

Our ACTblade e130 system provides up to four independent compute nodes with 24 drives in one chassis. This blade is ideal as a hyper-converged node.

  • CPU per node

    2x up to 32 core AMD Processors (EPYC)

  • MEMORY per node

    16x DDR4 2666MHz DIMM sockets (Max: 2 TB)

  • STORAGE per node

    6x 2.5" SATA drive bays (Max: 23.04 TB)

  • CONNECTIVITY per node

    Onboard 2x 1Gb NICs & Optional: 10GbE, 40GbE, InfiniBand, 100GbE

  • DENSITY

    Compute Block multi-node rackmount chassis with redundant power

ACTblade x210

Our ACTblade x210 system provides up to four independent compute nodes in one chassis. This blade is ideal as a compute node.

  • CPU per node

    2x up to 28 core Intel Xeon SP (Cascade Lake)

  • MEMORY per node

    16x DDR4 2933MHz DIMM sockets (Max: 1 TB)

  • STORAGE per node

    1x 2.5" SSD drive bays (Max: 3.84 TB)

  • CONNECTIVITY per node

    Onboard 2x 10Gb NICs & Optional: 10GbE, 40GbE, InfiniBand, OmniPath, 100GbE

  • DENSITY

    Compute Block multi-node rackmount chassis with redundant power

ACTblade x220

Our ACTblade x220 compute node is your general purpose HPC compute node and supports lower wattage, lower core count cpus. This blade has the capacity to provide more storage than the ACTblade x210.

  • CPU per node

    2x up to 22 core Intel Xeon SP (Cascade Lake)

  • MEMORY per node

    16x DDR4 2933MHz DIMM sockets (Max: 1 TB)

  • STORAGE per node

    3x 3.5"SATA,SSD drive bays (Max: 36 TB)

  • CONNECTIVITY per node

    Onboard 2x 10Gb NICs & Optional: 10GbE, 40GbE, InfiniBand, OmniPath, 100GbE

  • DENSITY

    Compute Block multi-node rackmount chassis with redundant power

ACTblade x230

Our ACTblade x230 system provides up to four independent compute nodes with 24 drives in one chassis. This blade is ideal as a hyper-converged node.

  • CPU per node

    2x up to 22 core Intel Xeon SP (Cascade Lake)

  • MEMORY per node

    16x DDR4 2933MHz DIMM sockets (Max: 1 TB)

  • STORAGE per node

    6x 2.5" SATA drive bays (Max: 23.04 TB)

  • CONNECTIVITY per node

    Onboard 2x 10Gb NICs & Optional: 10GbE, 40GbE, InfiniBand, OmniPath, 100GbE

  • DENSITY

    Compute Block multi-node rackmount chassis with redundant power

ACTserv e1115

The ACTserv e1115 is a dual socket AMD EPYC 1U system that offers 128x PCIe lanes. Ideal for high memory and storage solutions.

  • CPU

    2x up to 32 core AMD Processors (EPYC)

  • MEMORY

    32x DDR4 2666MHz DIMM sockets (Max: 4 TB)

  • STORAGE

    10x 2.5" SATA,SSD,NVMe drive bays (Max: 40 TB)

  • CONNECTIVITY

    Onboard 2x 1Gb NICs & Optional: 10GbE, 40GbE, InfiniBand, 100GbE

  • DENSITY

    1U rackmount chassis with redundant power

ACTserv e1120

The ACTserv e1120 is a dual socket AMD EPYC 1U system that offers 128x PCIe lanes. Ideal for high memory and storage solutions.

  • CPU

    2x up to 32 core AMD Processors (EPYC)

  • MEMORY

    32x DDR4 2666MHz DIMM sockets (Max: 4 TB)

  • STORAGE

    4x 3.5"SATA,SSD,NVMe drive bays (Max: 56 TB)

  • CONNECTIVITY

    Onboard 2x 1Gb NICs & Optional: 10GbE, 40GbE, InfiniBand, 100GbE

  • DENSITY

    1U rackmount chassis with redundant power

ACTserv e2120c

Our ACTserv e2120 is an ideal EPYC head or storage node. The addition of 2x expansion slots for GPUs also makes it a great compute node for accelerators.

  • CPU

    2x up to 32 core AMD Processors (EPYC)

  • MEMORY

    32x DDR4 2666MHz DIMM sockets (Max: 4 TB)

  • STORAGE

    8x 3.5"SATA,SSD drive bays (Max: 96 TB)

  • ACCELERATORS

    Max 2x NVIDIA Tesla accelerators

  • CONNECTIVITY

    Onboard 2x 10Gb NICs & Optional: 10GbE, 40GbE, InfiniBand, 100GbE

  • DENSITY

    2U rackmount chassis with redundant power

ACTserv e2150

Our ACTserv e2150 supports high core count, high frequency cpus and offers a lot of fast NVMe storage. It can be used as a fast storage, or head node.

  • CPU

    2x up to 32 core AMD Processors (EPYC)

  • MEMORY

    32x DDR4 2666MHz DIMM sockets (Max: 1.5 TB)

  • STORAGE

    24x 2.5" NVMe drive bays (Max: 192 TB)

  • CONNECTIVITY

    Onboard 2x 1Gb NICs & Optional: 10GbE, 40GbE, InfiniBand, 100GbE

  • DENSITY

    2U rackmount chassis with redundant power

ACTserv e2180c

Our ACTserv e2180c is an ideal EPYC head or storage node. The addition of 2x expansion slots for GPUs also makes it a great compute node for accelerators.

  • CPU

    1x up to 32 core AMD Processors (EPYC)

  • MEMORY

    8x DDR4 2666MHz DIMM sockets (Max: 512 GB)

  • STORAGE

    8x 3.5"SATA,SSD drive bays (Max: 38.72 TB)

  • ACCELERATORS

    Max 8x NVIDIA Tesla accelerators

  • CONNECTIVITY

    Onboard 2x 1Gb NICs & Optional: 10GbE, 40GbE, InfiniBand, OmniPath, 100GbE

  • DENSITY

    2U rackmount chassis with redundant power

ACTserv x1210

Our ACTserv x1210 supports high core count, high frequency cpus and large memory capacity. This server is ideal for use as a compute, storage or head node.

  • CPU

    2x up to 28 core Intel Xeon SP (Cascade Lake)

  • MEMORY

    24x DDR4 2933MHz DIMM sockets (Max: 1.5 TB)

  • STORAGE

    8x 2.5" SATA drive bays (Max: 30.72 TB)

  • CONNECTIVITY

    Onboard 2x 10Gb NICs & Optional: 10GbE, 40GbE, InfiniBand, OmniPath, 100GbE

  • DENSITY

    1U rackmount chassis with redundant power

ACTserv x1215

Our ACTserv x1215 supports high core count, large memory and offers a lot of fast storage. This server is ideal for use as a compute, storage or head node.

  • CPU

    2x up to 28 core Intel Xeon SP (Cascade Lake)

  • MEMORY

    24x DDR4 2933MHz DIMM sockets (Max: 1.5 TB)

  • STORAGE

    8x 2.5" NVMe drive bays (Max: 64 TB)

  • CONNECTIVITY

    Onboard 2x 10Gb NICs & Optional: 10GbE, 40GbE, InfiniBand, OmniPath, 100GbE

  • DENSITY

    1U rackmount chassis with redundant power

ACTserv x1220

Our ACTserv x1220 supports high core count, high frequency cpus and offers a lot of fast storage. This server is ideal for use as a compute, storage or head node.

  • CPU

    2x up to 28 core Intel Xeon SP (Cascade Lake)

  • MEMORY

    24x DDR4 2933MHz DIMM sockets (Max: 1.5 TB)

  • STORAGE

    8x 2.5" SATA,SSD,NVMe drive bays (Max: 64 TB)

  • CONNECTIVITY

    Onboard 2x 10Gb NICs & Optional: 10GbE, 40GbE, InfiniBand, OmniPath, 100GbE

  • DENSITY

    1U rackmount chassis with redundant power

ACTserv x1270c

This server is ideal for use in hyper-converged, data analytics, cloud and high performance computing applications.

  • CPU

    1x up to 28 core Intel Xeon SP (Cascade Lake)

  • MEMORY

    12x DDR4 2666MHz DIMM sockets (Max: 768 GB)

  • STORAGE

    2x 2.5" SSD drive bays (Max: 15.36 TB)

  • ACCELERATORS

    Max 4x NVIDIA Tesla accelerators

  • CONNECTIVITY

    Onboard 2x 10Gb NICs & Optional: 10GbE, 40GbE, InfiniBand, OmniPath, 100GbE

  • DENSITY

    1U chassis

ACTserv x2210

Our ACTserv x2210 supports high core count, high frequency cpus and offers a lot of fast storage. It can be used as a compute, storage, head node or 2x GPU node. Provides option to add two GPUs.

  • CPU

    2x up to 28 core Intel Xeon SP (Cascade Lake)

  • MEMORY

    24x DDR4 2933MHz DIMM sockets (Max: 1.5 TB)

  • STORAGE

    8x 2.5" SATA,SSD,NVMe drive bays (Max: 64 TB)

  • ACCELERATORS

    Max 2x NVIDIA Tesla accelerators

  • CONNECTIVITY

    Onboard 2x 10Gb NICs & Optional: 10GbE, 40GbE, InfiniBand, OmniPath, 100GbE

  • DENSITY

    2U rackmount chassis with redundant power

ACTserv x2220

Our ACTserv x2220 is a general purpose node for more capacity in a smaller form factor. It is ideal as a head or storage node.

  • CPU

    2x up to 22 core Intel Xeon SP (Cascade Lake)

  • MEMORY

    24x DDR4 2933MHz DIMM sockets (Max: 1.5 TB)

  • STORAGE

    8x 3.5"SATA,SSD drive bays (Max: 96 TB)

  • CONNECTIVITY

    Onboard 2x 10Gb NICs & Optional: 10GbE, 40GbE, InfiniBand, OmniPath, 100GbE

  • DENSITY

    2U rackmount chassis with redundant power

ACTserv x2280c

Our ACTserv x2280c is a perfect balance 2x Xeon SP CPUs, 8x GPUs and storage.

  • CPU

    2x up to 26 core Intel Xeon SP (Cascade Lake)

  • MEMORY

    24x DDR4 2919MHz DIMM sockets (Max: 6 TB)

  • STORAGE

    8x 3.5"SATA,SSD drive bays (Max: 96 TB)

  • ACCELERATORS

    Max 8x NVIDIA Tesla, NVIDIA Quadro, NVIDIA GTX accelerators

  • CONNECTIVITY

    Onboard 2x 1Gb NICs & Optional: 10GbE, 40GbE, InfiniBand, OmniPath, 100GbE

  • DENSITY

    2U rackmount chassis with redundant power

ACTserv x4210

This server is ideal for use as a workstation or head node.

  • CPU

    2x up to 28 core Intel Xeon SP (Cascade Lake)

  • MEMORY

    16x DDR4 2933MHz DIMM sockets (Max: 1000 GB)

  • STORAGE

    8x 3.5"SATA,SSD drive bays (Max: 96 TB)

  • CONNECTIVITY

    Onboard 2x 10Gb NICs & Optional: 10GbE, 40GbE, InfiniBand, OmniPath, 100GbE

  • DENSITY

    4U rackmount chassis

ACTstor x2250

Our ACTstor x2250 offers the option of an all-flash array using NVMe drives to provide world-class speed and ultra-low latency for the most demanding storage needs.

  • CPU

    2x up to 28 core Intel Xeon SP (Cascade Lake)

  • MEMORY

    24x DDR4 2933MHz DIMM sockets (Max: 1.5 TB)

  • STORAGE

    24x 2.5" NVMe drive bays (Max: 192 TB)

  • CONNECTIVITY

    Onboard 2x 10Gb NICs & Optional: 10GbE, 40GbE, InfiniBand, OmniPath, 100GbE

  • DENSITY

    2U rackmount chassis with redundant power
