A newer version of this model is now available
This model has been replaced by a newer model, the ACTserv x2110.
  • CPU

    2x up to 44 core Intel Xeon E5v4 (Broadwell)

  • MEMORY

    16x DDR4 2400MHz DIMM sockets (Max: 1 TB)

  • STORAGE

    10x 2.5" SATA,SSD drive bays (Max: 16 TB)

  • ACCELERATORS

    Max 4x NVIDIA Tesla accelerators

  • CONNECTIVITY

    Onboard 2x 1Gb NICs & Optional: 10GbE, 40GbE, InfiniBand, OmniPath, 100GbE

  • DENSITY

    2U rackmount chassis with redundant power

Discounts are available for volume, education and government customers. Request a quote for product and pricing details.

Technical Specifications

In the box
  • Server system
  • Rackmount hardware
  • 110V or 208V power cord
  • Documentation
Processor
  • 2x Intel Xeon E5-2600v4 series processors
  • Intel "Broadwell" microarchitecture
  • Integrated memory controller and 2x QPI interconnects per socket
  • 14nm process technology
Accelerators
  • Up to 4x Tesla P100 GPUs
Chipset
  • Intel C612 series
Memory
  • 2400MHz DDR4 memory
  • 16x DIMM sockets for support up to 1024GB
Storage
  • 10x 2.5" hot-swap SATA drive bays
  • Support RAID level 0,1,10,5,6 with Linux software RAID or optional hardware RAID controller
  • Support for high-performance solid state drives (SSD)
Management
  • Integrated IPMI 2.0 module
  • Integrated management controller providing iKVM and remote disk emulation
I/O Connections
  • 4x open PCI-e 3.0 expansion slots running at 16x; 1x open PCI-e 3.0 expansion slots running at 8x
  • 2x independent 1Gb RJ-45 ethernet interfaces
  • 2x USB 3.0 ports
  • 1x VGA port
Electrical requirements
  • High-efficiency power supply (greater than 80%)
  • Output power: redundant 2000W
  • Universal input voltage 100V to 240V
  • Frequency: 50Hz to 60Hz, single phase
Size & Weight
  • Height: 3.5 inches (2U)
  • Width: 19 inches
  • Depth: 26 inches
  • Weight: Base config 75lbs, varies based on configuration
Operating System
  • RedHat Linux 6 and newer (most other distributions supported, call for details)
