ACTserv e1110

The ACTserv e1110 is a dual socket AMD EPYC 1U system that offers 128x PCIe lanes. Ideal for high memory and storage solutions.

  • CPU

    2x up to 32 core AMD Processors (EPYC)

  • MEMORY

    32x DDR4 2666MHz DIMM sockets (Max: 4 TB)

  • STORAGE

    4x 3.5"SATA,SSD drive bays (Max: 40 TB)

  • DENSITY

    1U rackmount chassis with redundant power

ACTserv x1110

Our ACTserv x1110 supports high core count, high frequency cpus and offers a lot of fast storage. This server is ideal for use as a compute, storage or head node.

  • CPU

    2x up to 28 core Intel Xeon SP (Skylake)

  • MEMORY

    24x DDR4 2666MHz DIMM sockets (Max: 1.5 TB)

  • STORAGE

    8x 2.5" SATA,SSD,NVMe drive bays (Max: 12.8 TB)

  • CONNECTIVITY

    Onboard 2x 10Gb NICs & Optional: 10GbE, 40GbE, InfiniBand, OmniPath, 100GbE

  • DENSITY

    1U rackmount chassis with redundant power

ACTserv x2110

Our ACTserv x2110 supports high core count, high frequency cpus and offers a lot of fast storage. It can be used as a compute, storage, head node or 2x GPU node. Provides option to add two GPUs.

  • CPU

    2x up to 28 core Intel Xeon SP (Skylake)

  • MEMORY

    24x DDR4 2666MHz DIMM sockets (Max: 1.5 TB)

  • STORAGE

    8x 2.5" SATA,SSD,NVMe drive bays (Max: 16 TB)

  • ACCELERATORS

    Max 2x NVIDIA Tesla accelerators

  • CONNECTIVITY

    Onboard 2x 10Gb NICs & Optional: 10GbE, 40GbE, InfiniBand, OmniPath, 100GbE

  • DENSITY

    2U rackmount chassis with redundant power

ACTserv x2120

Our ACTserv x2120 is a general purpose node for more capacity in a smaller form factor. It is ideal as a head or storage node.

  • CPU

    2x up to 22 core Intel Xeon SP (Skylake)

  • MEMORY

    24x DDR4 2666MHz DIMM sockets (Max: 1.5 TB)

  • STORAGE

    8x 3.5"SATA,SSD drive bays (Max: 80 TB)

  • CONNECTIVITY

    Onboard 2x 10Gb NICs & Optional: 10GbE, 40GbE, InfiniBand, OmniPath, 100GbE

  • DENSITY

    2U rackmount chassis with redundant power

ACTstor x2150

Our ACTstor x2150 offers the option of an all-flash array using NVMe drives to provide world-class speed and ultra-low latency for the most demanding storage needs.

  • CPU

    2x up to 28 core Intel Xeon SP (Skylake)

  • MEMORY

    24x DDR4 2666MHz DIMM sockets (Max: 1.5 TB)

  • STORAGE

    24x 2.5" NVMe drive bays (Max: 38.4 TB)

  • CONNECTIVITY

    Onboard 2x 10Gb NICs & Optional: 10GbE, 40GbE, InfiniBand, OmniPath, 100GbE

  • DENSITY

    2U rackmount chassis with redundant power

Pinnacle 1X3601H8

This configuration is ideal for use as a head node or a compute node that needs additional storage.

A newer version of this model is available: ACTserv x1110.
  • CPU

    2x up to 22 core Intel Xeon E5v4 (Broadwell)

  • MEMORY

    24x DDR4 2400MHz DIMM sockets (Max: 1.5 TB)

  • STORAGE

    8x 2.5" SATA,SSD drive bays (Max: 12.8 TB)

  • CONNECTIVITY

    Onboard 2x 1Gb NICs & Optional: 10GbE, 40GbE, InfiniBand, OmniPath, 100GbE

  • DENSITY

    1U rackmount chassis with redundant power

Pinnacle 2X3602H8

This server features integrated dual 10 gigabit base-T NICs and and 8x 2.5" hot swap drive bays.

A newer version of this model is available: ACTserv x2110.
  • CPU

    2x up to 44 core Intel Xeon E5v4 (Broadwell)

  • MEMORY

    24x DDR4 2400MHz DIMM sockets (Max: 1.5 TB)

  • STORAGE

    8x 2.5" SATA,SSD drive bays (Max: 12.8 TB)

  • ACCELERATORS

    Max 2x NVIDIA Tesla accelerators

  • CONNECTIVITY

    Onboard 2x 10Gb NICs & Optional: 40GbE, InfiniBand, OmniPath, 100GbE

  • DENSITY

    2U rackmount chassis with redundant power

Pinnacle 2X3603H8

This server features integrated dual 10 gigabit base-T NICs and and 8x 3.5" hot swap drive bays.

A newer version of this model is available: ACTserv x2110.
  • CPU

    2x up to 44 core Intel Xeon E5v4 (Broadwell)

  • MEMORY

    24x DDR4 2400MHz DIMM sockets (Max: 1.5 TB)

  • STORAGE

    8x 3.5" & 2x 2.5" SATA,SSD drive bays (Max: 80 TB)

  • ACCELERATORS

    Max 2x NVIDIA Tesla accelerators

  • CONNECTIVITY

    Onboard 2x 10Gb NICs & Optional: 40GbE, InfiniBand, OmniPath, 100GbE

  • DENSITY

    2U rackmount chassis with redundant power

Pinnacle 3X3601H16

This 3U storage server with 16 drive bays is ideal for use as a head node or storage node.

A newer version of this model is available: ACTstor x4150.
  • CPU

    2x up to 44 core Intel Xeon E5v4 (Broadwell)

  • MEMORY

    16x DDR4 2400MHz DIMM sockets (Max: 512 GB)

  • STORAGE

    16x 3.5" & 2x 2.5" SATA,SSD drive bays (Max: 160 TB)

  • CONNECTIVITY

    Onboard 2x 10Gb NICs & Optional: 40GbE, InfiniBand, OmniPath, 100GbE

  • DENSITY

    3U rackmount chassis with redundant power
