ACTserv x1170c

This server is ideal for use in hyper-converged, data analytics, cloud and high performance computing applications.

  • CPU

    1x up to 28 core Intel Xeon SP (Skylake)

  • MEMORY

    12x DDR4 2666MHz DIMM sockets (Max: 768 GB)

  • STORAGE

    2x 2.5" SSD drive bays (Max: 4 TB)

  • ACCELERATORS

    Max 4x NVIDIA Tesla accelerators

  • CONNECTIVITY

    Onboard 2x 10Gb NICs & Optional: 10GbE, 40GbE, InfiniBand, OmniPath, 100GbE

  • DENSITY

    1U chassis

ACTserv x2110

Our ACTserv x2110 supports high core count, high frequency cpus and offers a lot of fast storage. It can be used as a compute, storage, head node or 2x GPU node. Provides option to add two GPUs.

  • CPU

    2x up to 28 core Intel Xeon SP (Skylake)

  • MEMORY

    24x DDR4 2666MHz DIMM sockets (Max: 1.5 TB)

  • STORAGE

    8x 2.5" SATA,SSD,NVMe drive bays (Max: 16 TB)

  • ACCELERATORS

    Max 2x NVIDIA Tesla accelerators

  • CONNECTIVITY

    Onboard 2x 10Gb NICs & Optional: 10GbE, 40GbE, InfiniBand, OmniPath, 100GbE

  • DENSITY

    2U rackmount chassis with redundant power

ACTserv x4170c

Our ACTserv x4170c is a GPU powerhouse with 2x Xeon SP CPUs and up to 8x GPUs

  • CPU

    2x up to 28 core Intel Xeon SP (Skylake)

  • MEMORY

    24x DDR4 2666MHz DIMM sockets (Max: 1.5 TB)

  • STORAGE

    14x 2.5" SATA,SSD drive bays (Max: 28 TB)

  • ACCELERATORS

    Max 8x NVIDIA Tesla, NVIDIA Quadro, NVIDIA GTX accelerators

  • CONNECTIVITY

    Onboard 2x 10Gb NICs & Optional: 10GbE, 40GbE, InfiniBand, OmniPath, 100GbE

  • DENSITY

    4U rackmount chassis with redundant power

GPU 2XG3602

Provides capacity for up to four GPUs in a 2U chassis.

A newer version of this model is available: ACTserv x2110.
  • CPU

    2x up to 44 core Intel Xeon E5v4 (Broadwell)

  • MEMORY

    16x DDR4 2400MHz DIMM sockets (Max: 1 TB)

  • STORAGE

    10x 2.5" SATA,SSD drive bays (Max: 16 TB)

  • ACCELERATORS

    Max 4x NVIDIA Tesla accelerators

  • CONNECTIVITY

    Onboard 2x 1Gb NICs & Optional: 10GbE, 40GbE, InfiniBand, OmniPath, 100GbE

  • DENSITY

    2U rackmount chassis with redundant power

Pinnacle 2X3602H8

This server features integrated dual 10 gigabit base-T NICs and and 8x 2.5" hot swap drive bays.

A newer version of this model is available: ACTserv x2110.
  • CPU

    2x up to 44 core Intel Xeon E5v4 (Broadwell)

  • MEMORY

    24x DDR4 2400MHz DIMM sockets (Max: 1.5 TB)

  • STORAGE

    8x 2.5" SATA,SSD drive bays (Max: 12.8 TB)

  • ACCELERATORS

    Max 2x NVIDIA Tesla accelerators

  • CONNECTIVITY

    Onboard 2x 10Gb NICs & Optional: 40GbE, InfiniBand, OmniPath, 100GbE

  • DENSITY

    2U rackmount chassis with redundant power

Pinnacle 2X3603H8

This server features integrated dual 10 gigabit base-T NICs and and 8x 3.5" hot swap drive bays.

A newer version of this model is available: ACTserv x2110.
  • CPU

    2x up to 44 core Intel Xeon E5v4 (Broadwell)

  • MEMORY

    24x DDR4 2400MHz DIMM sockets (Max: 1.5 TB)

  • STORAGE

    8x 3.5" & 2x 2.5" SATA,SSD drive bays (Max: 80 TB)

  • ACCELERATORS

    Max 2x NVIDIA Tesla accelerators

  • CONNECTIVITY

    Onboard 2x 10Gb NICs & Optional: 40GbE, InfiniBand, OmniPath, 100GbE

  • DENSITY

    2U rackmount chassis with redundant power
